Dahon Launch D8
This item is currently not available.
Details
Prepare for LAUNCH and a completely new way of folding. The Jaws hinge is the next evolution in Dahon LockJaw technology.
Seamless and sturdy teeth lock the hydroformed lightweight aluminum frame into place, while its 8 speeds and Dahon custom tires brace you for a powerful journey ahead.
The Launch D8 is equipped with Dahon's proprietary Deltec cable system offering increased frame stiffness and increasing the maximum rider weight limit to 300lbs (137kg) along with a 10 year warranty.
Specs
| Frame | Dalloy Aluminum Sonus Tubeset, Lattice Forged Jaws Hinge |
|---|---|
| Fork | Smooth Riding and Stable Hi-Ten Steel Blades and Steerer |
| Headset | Fusion, Zero Stack, Cartridge Bearing |
| Rear Shock | N/A |
| Rims/Wheels | 20" Lightweight Aluminum Double Wall Disc |
| Hubs | F: DAHON Custom 100mm 28 Hole Disc R: DAHON Custom 135mm 28 Hole DIsc 8 spd cassette |
| Spokes | 14g Stainless Steel |
| Tires | DAHON Custom 20"*1.75" |
| Crankset | Forged Aluminum 53 Tooth Chainring w/ Single CNC Guard |
| Chainwheel | Forged Aluminum 53 Tooth Chainring w/ Single CNC Guard |
| Bottom Bracket | Sealed Bearing |
| Chain | YNB |
| Front Derailleur | N/A |
| Rear Derailleur | DAHON Custom 8-Speed Rear Derailleur |
| Rear Cogs | Sunrace 8 Speed, 11-32T |
| Shifters | DAHON Custom 8-Speed Trigger Shifter |
| Handlebars | 6061 Double Butted Aluminum Flat Bar 580mm Wide |
| Tape/Grips | DAHON Ergo Comfort |
| Stem | Forged Aluminum Radius Telescope w/ Fusion Technology, Adjustable |
| Brake Levers | DAHON Custom 2.5 Finger Aluminum Lever |
| Brakes | TEKTRO Mechanical Disc |
| Pedals | DAHON Foldable, PC Body, Aluminum Cage |
| Saddle | DAHON Ergo Comfort |
| Seat Post | DAHON Custom 6061 Aluminum, 33.9mm x 580mm |
| Seat Binder | Included |
| Accessories & Extras | Kickstand Lightweight Aluminum |
| Color(s) | WHITE |
| Sizes | OS |
| Folded Dimensions | 25x15x32in (64x38x82cm) |
| Weight | 27lbs (12.3kg) |
* Subject to change without notice.
