Haro PD4 - 2020

Haro PD4
Size: Select size
Please select options Unavailable


The PD4 does it all. Built using X6 series lightweight aluminum, the PD4 frame features a tapered internal headset and internal cable routing to keep a clean frame and its housing tucked away. Its 1x drive train provides a wide gear ratio, yet keeps things light and simple with no front derailleur and shifter to deal with. Lightweight and durable Weinmann U-28 alloy double wall rims are strong and built to last and matched to Kenda's Kwick Seven.5 tires with reflective sidewalls. On top of this, the PD4 features a Shimano 11-speed Deore XT Shadow rear derailleur and a RockShox Judy Silver suspension fork complete with a remote lockout that allows you to create a rigid fork on the fly, when needed.


Frame Haro PD4 27.5" X6 alloy frame
Fork Judy Silver, 27.5" Boost fork, 100mm, w/ remote Lockout
Headset FPD DOZER-1160A-2, 1.5" ACB bottom, for 44/56mm Head Tube, w/ 15mm top cap
Rear Shock N/A
Rims/Wheels Weinmann U-28 DW 27.5" rims
Hubs Alivio / Altus, Front T/A, 36h hubs
Spokes Stainless steel, Black E.D.
Tires Kwick Seven.5 27.5x2.0", 60TPI, w/ Reflective Stripes
Crankset FSA Comet Modular MegaExo, 32T, Megatooth Chromoly Chainring
Bottom Bracket FSA MegaExo 73mm
Chain KMC X11 11-spd
Front Derailleur N/A
Rear Derailleur Shimano Deore XT, 11-spd Shadow Plus
Rear Cogs Shimano SLX M7000, 11-spd, 11-46T
Shifters Shimano SLX M7000, 11-spd
Handlebars Pivit alloy 25mm riser 31.8mm
Tape/Grips Velo Triple Density w/ integrated Bar-Ends
Stem Pivit Adjustable stem, 31.8x105mm / 1-1/4"x4.125"
Brake Levers Shimano BL-T4000, Deore, cable type, 2-finger
Brakes Shimano BR-M375 mechanical, 180/160mm Center Lock Rotors
Pedals VP 335T w/ Toe clips and Straps
Saddle WTB Comfort Sport
Seat Post Pivit alloy, 2 Bolts, micro adjust 30.9mm
Seat Binder Pivit alloy 34.9mm quick release
Accessories & Extras Rear rack, Water-Bottle cage
Sizes S, M, L, XL

* Subject to change without notice.

Part Numbers

Option MPN Store SKU
MATTE BLACK / Small 10586 15820PD4+1
MATTE BLACK / Medium 10587 15820PD4+2
MATTE BLACK / Large 10588 15820PD4+3
MATTE BLACK / X-Large 10589 15820PD4+4
